Artificial Intelligence in gamesThe Python Tutorial

Paweł Widera

What is this about?

Tutorial organisation

Copy fragments of code from slides to your editor
or download complete code using the link at a slide corner.

http://tinyurl.com/pyne-ai-games


Feel free to ask questions at any time!

Experiment with the code, make it yours.

Setup

*game engine adapted from the code published by CodinGame

>$ java -jar runner.jar

Usage: java -jar runner.jar <bot1> <bot2> [-r]
for Firefox in about:config
"dom.moduleScripts.enabled" == True

The Game

Hints

CC-BY Computer Laboratory, University of Cambridge

OXO

Tic-tac-toe


m x n board with k in a row to win

Ultimate Tic-tac-toe


Response time: 100ms except 1st turn (1s)
https://www.theofekfoundation.org/games/UltimateTicTacToe/

Input / Output


<board> <square>

Simple AI

Let's make some moves

code
while True:
  board, square = [int(x) for x in input().split()]

  count = int(input())

  moves = []
  for i in range(count):
    board, square = [int(x) for x in input().split()]
    moves.append((board, square))

  move = moves[0]
  print(move[0], move[1])


AI system is an intelligent agent that can decide
what actions to take and when to take them

  # debugging
  import sys
  print(x, file=sys.sdterr)

Move lottery

code
Move = namedtuple("Move", "board square")


def read_move():
  return Move(*map(int, input().split()))


def write_move(move):
  print(move.board, move.square)
while True:
  enemy_move = read_move()

  count = int(input())
  moves = [read_move() for i in range(count)]

  write_move(random.choice(moves))

Move evaluation

code
CORNERS = {0, 2, 6, 8}
CENTRE = 4


def evaluate(move):
  if move.square in CORNERS:
    return 2
  if move.square == CENTRE:
    return 1
  return 0
while True:

  ...

  move = max(moves, key=evaluate)
  write_move(move)

State evaluation

code
boards = tuple([0 for i in range(9)] for i in range(9))

while True:
  # place opponents move
  enemy_move = read_move()
  if enemy_move.board >= 0:
    boards[enemy_move.board][enemy_move.square] = -1

  ...

  # place my move
  boards[move.board][move.square] = 1
DIAGONALS = ((0, 4, 8), (2, 4, 6))
COLUMNS = ((0, 3, 6), (1, 4, 7), (2, 5, 8))
ROWS = ((0, 1, 2), (3, 4, 5), (6, 7, 8))
LINES = ROWS + COLUMNS + DIAGONALS


def evaluate(move):
  current = boards[move.board].copy()
  current[move.square] = 1

  if any(sum(current[x] for x in line) == 3 for line in LINES):
    return 10

  ...

Game ending

code
State = namedtuple("State", "meta boards")

...

meta = [0 for i in range(9)]
boards = tuple([0 for i in range(9)] for i in range(9))
state = State(meta, boards)
def has_line(board, player=1):
  return any(sum(board[x] for x in line) == player * 3 for line in LINES)

def update(state, move, player):
  current = state.boards[move.board]
  current[move.square] = player
  if has_line(current, player):
    state.meta[move.board] = player
  return current
def evaluate(move):
  new_state = deepcopy(state)
  new_board = update(new_state, move, 1)

  if has_line(new_state.meta):
    return 100
  if has_line(new_board):
    return 10
  return 0

Not helping the opponent...

code
def under_threat(board):
  return any(sum(board[x] for x in line) == -2 for line in LINES)


def evaluate(move):

  ...

  next_board = new_state.boards[move.square]
  if under_threat(next_board):
    return -10

  ...

def evaluate(move):

  ...

  new_state.meta[move.square] = -1
  if has_line(new_state.meta, -1) and under_threat(next_board):
    return -100

  ...

Forward thinking

Minimax algorithm

def best_enemy_play(move):
  new_state = deepcopy(state)
  update(new_state, move)

  best = -1000
  for enemy_move in valid_moves(new_state, move.square):
    best = max(best, evaluate(new_state, enemy_move, -1))
  return best

...

  # choose best move
  move = min(moves, key=best_enemy_play)
def game_over(meta):
  return any(abs(sum(meta[x] for x in line)) == 3 for line in LINES)

def valid_moves(state, next_board):
  if game_over(state.meta):
    return []

  # next board is playable (not captured and not full)
  if (state.meta[next_board] == 0 and not all(state.boards[next_board])):
    return (Move(next_board, x) for x in range(9) if state.boards[next_board][x] == 0)

  # cannot play on the next board, list valid moves on all other boards
  boards = (x for x in range(9) if state.meta[x] == 0)
  return (Move(b, x) for b in boards for x in range(9) if state.boards[b][x] == 0)

Minimax evaluation

code
def evaluate(state, move, player):
  new_state = deepcopy(state)
  new_board = update(new_state, move, player)
  next_board = new_state.boards[move.square]

  if has_line(new_state.meta, player):
    return 100

  new_state.meta[move.square] = -player
  if has_line(new_state.meta, -player) and under_threat(next_board, -player):
    return -100

  if has_line(new_board, player):
    return 10

  if under_threat(next_board, -player):
    return -10

  if under_threat(new_state.meta, player):
    return 5

  # free grid choice for the opponent
  if new_state.meta[move.square] != 0:
    return -5

  return 0

Guessing the future

Tournament

Rules

http://192.168.4.207:8800/



Other options: USB stick or https://send.firefox.com
